Quantitative qualitative adjustment analyzer laboratory Ultra-micro spectrophotometer

Measurement data
Minimum sample size0.5 μl
Optical path1mm / 0.2mm
Wavelength range190 ~ 850nm
 Wavelength accuracy1 nm
 Wavelength resolution≤0.3nm (FWHM at Hg 253.7nm)
 Absorbance accuracy2% (0.76 at 257nm)
 Absorbance resolution accuracy0.002Abs (1mm optical path)
 Absorbance range0.02 ~ 300 (equivalent to 10mm optical path)
 Accurate measurement range0.1 ~ 5 Abs. ± 0.1Abs 5 ~ 80 Abs. ± 2%
 Detector3648 pixel linear CCD array
 Light sourceMini Xenon flash system
 Measurement time<5 seconds
 Size200mm × 130mm × 136mm (L × W × H)
 Weight≤ 2.0kg
 Sample test platform material304 stainless steel and quartz
 Input voltageAC100 ~ 240V 50-60Hz
 Operating power24W

Instrument Features:

1. The amount of sample required for detection is as low as 0.5ul;

2. Wide detection range, 100 times higher than the upper limit of traditional spectrophotometer;

3. No dilution required for most samples;

4. The machine does not require preheating, direct measurement, no need to detect the container, and low daily consumption;

5. Full wavelength 190-1100nm, resolution 1nm, the instrument will automatically give full wavelength scanning results 190-850nm;

6. Small size, portable packaging, meet the needs of field testing;

7. More precise and flexible measurement through PC control ;
