Dalong DLAB 20L LCD Numerical Control Top-mounted Strong Electronic Agitator OS20-S

Features

  • High reliability and outstanding performance.
  • A wide range of speed from 50 to  2200rpm.
  • Brushless DC motor for long life, maintenance free and explosion proof.
  • LED screen for monitoring actual speed.
  • Safety circuits allow for safe stop function in anti-stall or overload conditions.

Technical Parameter

SpecificationsOS20-S
Max. stirring quantity(H2O)20L
Motor typebrushless DC motor
Motor input power60W
Motor output power50W
Voltage100-240V, 50/60 Hz
Power70W
Speed range50-2200rpm
Speed display accuracy±3rpm
Speed displayLED
Overload protection displayLED lights
Max. torque40Ncm
Viscosity max.10000mPas
Chuck range diameter0.5-10mm
Dimension[WxHxD]83x220x186mm
Weight2.8kg
Protection classIP42
Permissible ambient temperature and humidity5-40°C, 80%RH

Company Profile

certifications1

Packing & Shipping

Before shipment, we have a final inspect to check the products Normally we can ship the goods within 5-15 days if we have the stock. If your quantity is huge big or your requirements are different and spe cial, we need to communicate and decide the accurate shipping date

packing

FAQ

A:Yes. We offer free samples, including customized samples. You only need to pay the freight. Sample delivery date is within 1-          3days, customized sample is about 3-7days.

A:Yes. We have our strict evaluation criteria of quality on our partner factory, and we did complete and detailed market research          and priced competitively.

A:We accept T/T, Visa, MasterCard, E-checking, L/C, Western Union and more.Please choose your preferred payment method. 4.How to inspect the goods?

A:Products will be checked by our QC staff first , then our project manager. Client can come and check by themselves or third             party check is available.
